1213Z2A 06 – LIT/OPTIONAL

1213Z2A 06 – LIT/OPTIONAL

Written by

in

1213Z2A 06 – LIT/OPTIONAL

Products

PositionProduct
xWire Harness
1WPY04100165 Whirlpool Surface Element
2WP112432 Whirlpool Nut Assembly
3Screw 8-32 x 1/2“
4Glass-Oven Door
5Screw 10-32 x 1/2“
6Keps Nut 8-32
7Cushion-Door Glass
8Frame-Door Glass
9Handle-Oven Door
10Screw 6Ax3/8“
11Retainer-Oven Door Insulation
12Insulation-Oven Door
13Module
13Switches-Gas Valve-All Models Except 14633A Models
13Switches-Gas Valve-All 14633A Models
13Lining-Oven Door
