1225^2A 02 – MAIN TOP

1225^2A 02 – MAIN TOP

Written by

in

1225^2A 02 – MAIN TOP

Products

PositionProduct
1Clip
2Wire Cover-Backguard
3Knurled Nut
4Crosstie
5Clock Motor
6Knob-Clock
7Screw 6-20×3/8“
8Clock (Inc`s. 5)
9Space
10Lock Nut
11Push Switch-Oven Light
12Screw 10ABx1/2“
13Screw 10-16×7/16“
14Support-Backguard (Left)
14Support-Backguard (Right)
14Support-Backguard
15Glass-Backguard
16Bezel-Backguard
17Screw 6-20×3/8“
18Trim-Crosstie
