1347^0A 03 – MAIN TOP

Products

Position	Product
1	Glass Top Assembly
2	Screw 6-20×3/8“
3	Screw 10-16×7/16“
4	End Trim-Top Lamp Glass (Lt. or Rt.)
5	Indicator Light
6	Thermostat-Oven
7	Mounting Panel-Controls
8	WPL 78565
9	Backguard Glass
10	Tubular Clip (4 Req.)
11	Clock w/4 Hr. Timer
12	Wire Cover
13	Support-Backguard (Lt. or Rt.)
14	Shield-Flue Deflector
15	Bottom Front-Backguard
16	Knob-Clock
17	Knob-Thermostat
18	Barrier-Thermostat
