1353W2A 08 – ROTISSERIE , GRIDDLE

1353W2A 08 – ROTISSERIE , GRIDDLE

Written by

in

1353W2A 08 – ROTISSERIE , GRIDDLE

Products

PositionProduct
250Outer Door Glass
251Fastener (7 Required)
252Insulation Retainer
253Insulation-Oven Door Lining
254Screw 10 – 32 x 1/4“
255Lockwasher
256Screw 10-32 x 1/2“
257Washer
258WPL 316365
259Plug-Oven Door Lining
260Gasket-Oven Door
261Screw 10-32×2-1/2“
262WPL 21067
263Stiffener-Oven Door Lining
264Insulation-Oven Door Plug
265Lining-Oven Door
266WP112432 Whirlpool Nut Assembly
267Screw 10-32×1“
268Shield-Oven Door Lining
269Front Panel-Oven Door (White)
269Front Panel-Oven Door (Golden Wheat)
269Front Panel-Oven Door (Almond)
270Top Frame-Oven Door Glass
271Spacer
272Cushion-Door Glass
273Frame-Oven Door Glass
274Handle
