1393W3A 06 – OVEN DOOR

1393W3A 06 – OVEN DOOR

Written by

in

1393W3A 06 – OVEN DOOR

Products

PositionProduct
1Range Service Cord
2Disconnect
3Wire Cover
4Stiffener – Body Side (Lt. or Rt.)
5WP112432 Whirlpool Nut Assembly
6Lower Support – Body Side (Left)
6Lower Support – Body Side (Right)
7Lockwasher
8Screw 10 – 32 x 7/16“
9Oven Door Hinge-Lt. or Rt. (Inc. Key 12)
10Spring-Oven Door (Lt. or Rt.)
11Shoulder rivet
12Screw 8ABx3/4“
13Washer
14Left
14Right
15Body Side w/Overlay-Rt. or Lt. (Inc. 71 & 74) (Toast)
15Body Side w/Overlay-Rt. or Lt. (Inc. 71 & 74) (Avocado)
15Body Side w/Overlay-Lt. or Rt.(Inc.56&69) (Golden Wheat)
15Body Side w/Overlay-Lt. or Rt.(Inc.56&69) (Almond)
15Body Side w/Overlay-Lt. or Rt.(Inc.56&69) (White)
15Body Side w/Overlay-Rt. or Lt. (Inc. 71 & 74) (Coffee)
15Body Side w/Overlay-Rt. or Lt. (Inc. 71 & 74) (Platinum)
16Baffel-Side Panel (Lt or Rt)
17Upper Insulation Retainer-Lt.
18Ballast
19Holder-Oven Light Bulb
20Bracket-Oven Lamp Holder
21Cover-Flue Deflector
22Retainer-Oven Light Insulation
23Oven Side-Left
24Insulation-Oven Top & Sides (1 Piece)
25Gasket-Lens
26Lens-Oven Light
27Access Plate
28Bottom-Oven Burner
29Main Bottom
30Base w/Levelers (Lt. or Rt.)
31Screw 10-32 x 1/2“
32Front-Snap On Panel
33Retainer – Seal
34W10900107 Whirlpool Oven Surface Element Switch
35Seal
36WPL 299263
37WPL 321162
38WPL 316365
39Retainer-Oven Light Lens
40Oven Lamp Bulb
41Shoulder Screw 10-32×1/2“
42Oven Back
43Cover Plate, Rotisserie
44Insulation-Oven Back
45WPL 282156
46Main Back
47Gasket-Flue Deflector
48Flue Deflector
49Oven Top
50WPL 285860
51Cover Plate-Thermostat Bulb
52Clip-Thermostat Bulb (2 Req)
53WPL 306150
53WPL 306149
54WPL 305361
55WPL 283457
56WPL 282127
57WPL 97220
58WPL 282118
59Catch-Strike
60WPL 304125
614396923 Whirlpool Broil Pan Set Gray Porcelain
62WPL 282952
63WPL 310977
64Speed Nut 10 – 32
65Screw 6-20×3/8“
66WPL 321919
67WPL 100576
68WPL 281574
69WPL 294195
70WPL 322073
71WPL 239603
72WPL 282278
73WPL 282273
74WPL 326070
75WPL 301769
