14-3088-00-02 03 – BURNER PARTS

14-3088-00-02 03 – BURNER PARTS

Written by

in

14-3088-00-02 03 – BURNER PARTS

Products

PositionProduct
*45499WIRE-IGNITOR (14 INCH)
*45501HARNESS-IGNITION
*45502316069301 Frigidaire Oven Burner Mounting Primary Screw
*45500WIRE-IGNITOR (20 INCH)
*45500WIRE-IGNITOR (30 INCH)
*45501WIRE-IGNITOR (36 INCH)
*45501HARNESS-HV GROUND
*45504WCI 5303210992
1WCI 5303209016
2WCI 5303209017
3VALVE TOP (3)
4VALVE TOP (1)
5WCI 5303209020
6WCI 5303209021
7BURNER-TOP
8BURNER-TOP
9SEAL BURNER (2) MED
10SEAL BURNER (2) LARGE
11WCI 5303209024
12WCI 5303209025
13WCI 5303209026
155304505695 Frigidaire Oven Module
16BURNER TOP LARGE (2)
17WCI 5303210088
18IGNITER CLIP (2)
19ORIFICE-TOP BURNER, (4)
20ORIFICE-MEDIUM
21BURNER TOP SMALL (2)
