1424^0A 05 – OVEN DOOR
Written by
in
1424^0A 05 – OVEN DOOR
Products
Position
Product
1
Shield – Flue Deflector
2
WP112432 Whirlpool Nut Assembly
3
Spacer-Main Top
4
Almond-Left
4
White-Right
4
White-Left
4
Wheat-Right
4
Wheat-Left
4
Almond-Right
4
Coffee
4
Body Side-Lt. (Avocado)
4
Body Side-Lt. (Coffee)
4
Avocado
5
Leg Leveler (4 Required)
6
Broiler Drawer
7
Broiler Pan
8
Broiler Pan Grid
9
Spring-Oven Door (Lt. or Rt.)
10
Nut-Retainer (2 Required)
11
Retainer-Insulation (Rt. or Lt.)
12
Grommet – Screw (8 Req.)
13
Oven Body
14
Insulation – Oven Back
15
Main Back
16
Screw 10 – 32 x 17/32“
17
Gasket-Flue Deflector
18
Flue Deflector
19
Insulation – Oven Top & Sides (1 Piece)
20
Thermostat Bulb Clip (2 Required)
21
Dart-Button Head (2 Required)
22
Screw 10-32 x 5/8“
23
Right
23
Left
24
Keps Nut 8-32
25
Washer
26
Catch-Broiler Door Strike
27
Thumbscrew-Rt. or Lt.
29
WPL 308975
29
Front Panel-Broiler
29
WPL 308976
29
WPL 308977
29
knob, control
30
Strike-Broiler Door
31
WP303896 Whirlpool High Limit Thermostat
32
Hinge-Broiler Door (Lt. or Rt.)
33
Washer
34
Shoulder Screw 10-32×1/2“
35
W10820036 Whirlpool Door Switch Kit
36
WPL 305409
37
WPL 305408
38
WPL 296069
39
WPL 101063
40
WPL 316994
41
WPL 314573
42
WPL 314574
43
Screw 10-32×3/8“
44
Lockwasher
45
WPL 302267
46
WPL 316365
47
Spacer-Broiler Doo
48
spacer-handle
49
Handle-Broiler Door
←
