| xParts Not Shown On Illustration |
| 1 | WPY04100165 Whirlpool Surface Element |
| 2 | WP112432 Whirlpool Nut Assembly |
| 3 | Screw 8-32 x 1/2`` |
| 4 | Glass-Oven Door |
| 5 | Screw 10-32 x 1/2`` |
| 6 | Keps Nut 8-32 |
| 7 | Cushion-Door Glass |
| 8 | Frame-Door Glass |
| 9 | Handle-Oven Door |
| 10 | Screw 6Ax3/8`` |
| 11 | Retainer-Oven Door Insulation |
| 12 | Insulation-Oven Door |
| 13 | Lining-Oven Door |
| 13 | Flue Collar Kit (Optional) |
| 13 | Gas Use & Care Guide |
| 13 | xOperating Guide |
| 13 | xInstallation & Reference Guide |
| 13 | xRepair Parts Manual |
