1435W1A 02 – MAIN TOP
Written by
in
1435W1A 02 – MAIN TOP
Products
Position
Product
1
Clock w/4 Hr. Timer (Inc`s. Key 3)
2
Clip-Clock (4 Req)
3
Clock Motor
4
Clock Glass
5
Knob-Clock (Start & Stop Time)
6
Clip
7
End Cap (Left)
7
End Cap (Right)
7
End Cap
8
Screw 6-20×3/8“
9
Screw 10-16×7/16“
10
Support-Backguard (Left)
10
Support-Backguard (Right)
10
Support-Backguard
11
Screw 10ABx1/2“
12
Push Switch-Oven Light
13
Lock Nut
14
14550A Models
14
Crosstie-Backguard
14
Crosstie-Backguard
15
Knurled Nut
16
Wire Cover-Backguard
17
Trim-Crosstie
←
