| 1 | Range Service Cord |
| 2 | Lockwasher |
| 4 | Screw 10 - 32 x 1/4`` |
| 5 | Clip |
| 6 | Rear Wire Cover |
| 7 | Hinge Angle - Lt or Rt |
| 8 | WPL 21067 |
| 10 | BURNER RECEPTACLE KIT |
| 11 | Hinge Box Asm. Lt or Rt |
| 12 | Insulation Retainer (Right 15250A, 15251A Models) |
| 12 | Insulation Retainer (Left 15250A, 15251A Models) |
| 12 | Insulation Retainer (Left 15252A, 15253A Models) |
| 12 | Insulation Retainer (Right 152521, 15253A Models) |
| 13 | Main Back |
| 14 | Gasket - Flue Deflector |
| 15 | Shield - Flue Deflector |
| 16 | Upper Wire Cover w/Flue Insulation Asm. |
| 17 | Disconnect |
| 18 | Bracket - Module |
| 19 | Flue Deflector |
| 20 | Support - Flue |
| 21 | Insulation Retainer - Oven Light |
| 22 | Thermostat Bulb Clip (2 Required) |
| 23 | Side Trim - Burner Box Bottom (Lt or Rt) |
| 24 | Screw 10ABx1 |
| 25 | Side Trim (Right) |
| 25 | Side Trim (Left) |
| 26 | Screw 8ABx5/8`` |
| 27 | Screw-10-32x1/2`` |
| 28 | Bottom Trim |
| 29 | Front Frame (15250A Models) |
| 29 | Front Frame (15251A, 15252A, 15253A Models) |
| 30 | Screw 10 - 32 x 17/32`` |
| 31 | Main Bottom |
| 32 | Oven Lamp Bulb |
| 33 | Holder-Oven Lamp Bulb |
| 34 | Oven Back (15251A, 15252A, 15253A Models) |
| 34 | Oven Back (15250A Models) |
| 35 | Oven Bottom (15250A Models) |
| 35 | Oven Bottom (15251A, 15252A, 15253A Model |
| 36 | WPL 282156 |
| 37 | WPL 315435 |
| 38 | Cooktop |
| 39 | WPL 305569 |
| 39 | WPL 305568 |
| 40 | WPL 293098 |
| 40 | WPL 331592 |
| 41 | WPL 326297 |
| 41 | WPL 293099 |
| 42 | Clip |
| 43 | WPL 332366 |
| 43 | WPL 328853 |
| 44 | WPL 282636 |
| 45 | WPL 332364 |
| 45 | WPL 332365 |
| 45 | WPL 328852 |
| 45 | WPL 328851 |
| 46 | WPL 281574 |
| 47 | WPL 288762 |
| 47 | WPL 332368 |
| 48 | WPL 305065 |
| 49 | WPL 292912 |
| 50 | WP112432 Whirlpool Nut Assembly |
