1745^0A 07 – CONTROL PANEL

Written by

Products

Position	Product
1	Screw 10-16×7/16“
2	Baffle – Airway
3	Foam Strip
4	Side – Compartment
5	Air Duct
6	Front – Blower Mounting Plate
7	Fan Blade
8	Support-Blower Motor
9	Motor – Blower
10	Nut 6-32
11	Set Screw 10-32
12	Mounting Plate – Blower
13	Convenience Outlet (With Wire Leads (1 Req))
13	WPL 109180
14	WPL 316365
