1765W0A 05 – BROILER AND OVEN BURNER
Written by
in
1765W0A 05 – BROILER AND OVEN BURNER
Products
Position
Product
1
Screw 10-16×7/16“
2
Rear Top Burner-Rt. or Lt. (Inc`s. Key 4)
3
Front Top Burner-Rt. or Lt. (Inc`s.Key 4)
4
Air Shutter
5
Left
5
Right
6
Support-Top Burner (Lt. or Rt.)
7
panel, side l.h. (almond panel, side r.h.)
8
Pressure Regulator
9
Mounting Screw (Inc`s 86)
10
Inverted Nut 3/8“
11
Shut Off Valve
12
Silicone Rubber Gasket
13
Manifold Pipe
14
Silicone Rubber Gasket (For Key 26)
15
Thermostat-Oven
16
G.M. Screw 8-32×3/16“
17
Shield-Thermostat
18
Gas Valve (4 Req)
19
Switch-Gas Valve (4 Req)
20
Tubing 3/8“ (Shut-Off Valve to Control Valve)
←
