1833W0A 02 – LOWER OVEN BURNER

Products

Position	Product
1	Top Grate (4 Required)
2	WPL 316365
3	Hinge (Right)
3	Hinge (Left)
4	Keps Nut 8-32
5	Washer
6	Screw 10 – 32 x 7/16“
7	Screw 10-32×3/8“
8	Burner Box Bottom
9	Knob-Thermostat
10	Knob-Gas Valve (4 Req)
11	Catch-Main Top Strike (2 Required)
12	White
12	Golden Wheat
12	Almond
13	Strike-Main Top (2 Required)
14	Washer
15	Almond
15	White
15	Golden Wheat
18	Spill Bowl
