1833W0A 03 – UPPER OVEN BURNER

Products

Position	Product
1	WP112432 Whirlpool Nut Assembly
2	Pilot Cup (3 Req)
3	Top Pilot Shield (3 Req)
4	Rear Top Burner-Lt. or Rt. (Inc`s 64 & 65)
5	Front Top Burner-Lt. or Rt. (Inc`s 64 & 65)
6	Adjustment Screw-Air Shutter
7	Air Shutter
8	Support-Top Burner
9	Pilot Tube (Inc`s. 13 & 14)
10	Pressure Regulator
11	Manifold Pipe
12	Filter-Top Pilot
13	Compression Nut 1/4``
14	Compression Ball Sleeve 1/4``
15	Tubing 3/8`` (Shut-Off Valve to Union)
16	Inverted Nut 3/8``
17	Shut Off Valve
18	Clip (10 Req)
19	Gasket
20	Gas Valve (4 Req)
21	Baffle - Oven Burner
22	Tubing 3/16`` -Oven Therm. To Oven Control Pilot
23	Compression Nut 3/16``
24	Orifice Cup Only
25	Pilot Head (Inc`s. 24)
26	WPL 316365
27	Loxit Nut 3/16``
28	Oven Thermostat
29	Fitting-Straight 3/8``
30	Screw 10-24x3/8``
31	Tubing 3/8`` (Shut-Off to Control Valve)
32	Oven Burner (Inc`s. 21, 33 & 34)
33	Adjustment Screw-Air Shutter
34	Aid Shutter
35	Screw 10-32x2``
36	Oven Control Valve
37	Screw 10-24x1/4``
38	Compression Ball Sleeve 3/16``
