1833W0A 04 – LOWER OVEN BODY

Products

Position	Product
1	Control Valve
2	Inverted Nut 3/8“
3	Compression Ball Sleeve 3/16“
4	Compression Nut 3/16“
5	Tubing 3/8“
6	Tubing 3/8“ (Shut-Off Valve to Union)
7	Union Connector 3/8“
8	Screw 10 – 32 x 1/4“
9	Air Shutter
10	Tubing 3/16“ (Control Valve to Flame Switch)
11	Flame Switch Only
12	Pilot & Bracket Only
13	Orifice Cup Only
14	All 18350A & 1A Models
