1872W0A 03 – BURNER

Products

Position	Product
1	Screw 10 – 32 x 7/16“
2	panel, side l.h. (almond panel, side r.h.)
3	Panel, Side L.H. (Platinum Panel, Side R.H.)
4	Rear Top Burner-Lt. or Rt. (Inc`s 64 & 65)
5	Front Top Burner-Lt. or Rt. (Inc`s 64 & 65)
6	Adjustment Screw-Air Shutter
7	Air Shutter
8	WP112432 Whirlpool Nut Assembly
9	Right
10	Wire Cover-Thermostat
13	Inverted Nut 3/8“
14	Shut Off Valve
15	Manifold Pipe
16	Fitting
17	Panel, Side L.H. (White)
21	Tubing 3/8“ (Shut-Off to Control Valve)
23	Cover – Ignitor Wires
24	Control Valve
25	Bracket-Control Valve
26	Nut 6-32
27	Air Shutter
28	Adjustment Screw -Air Shutter
29	Oven Burner (Inc. Keys 27, 28 & 30)
30	Baffle – Oven Burner
31	WPL 316365
32	Silicone Rubber Gasket
33	Screw 10 – 32 x 1/4“
34	Igniter – Bake or Broil
35	Bracket – Ignitor Mounting
36	Sleeve-Igniter Wire (Lt. or Rt.)
37	Pressure Regulator
38	Support-Top Burner
39	Bracket-Igniter
40	Mounting Screw (Inc`s 86)
41	Gasket (For 81)
42	Gas Valve (4 Req, Inc`s 32)
