1883^0A 06 – UPPER OVEN BURNER

Products

Position	Product
1	Screw 10ABx1
2	WPL 21067
3	Seal-Inner Glass
4	Screw 10-32 x 1/2“
5	Insulation Oven Door Plug
6	Gasket-Oven Door
7	Insulation-Oven Door Lining
8	Side Insulation-Lt. or Rt.
9	Left
9	Right
9	Retainer-Side Insulation
10	WP112432 Whirlpool Nut Assembly
11	Spacer-Oven Door Glass (Lt. or Rt.)
12	WP487353 Whirlpool Refrigerator Screw
13	Screw 10 – 32 x 1/4“
14	Front Panel-Oven Door
15	Outer Door Glass
16	Frame-Oven Door Glass
17	Cushion-Door Glass
18	Handle-Oven Door
19	Shield-Oven Door Lining
20	Oven Door Glass-Intermediate
21	Inner Glass-Oven Door
22	Insulation Retainer
23	Retainer-Oven Door Glass Insulation
24	Lining-Oven Door
25	Stiffener-Oven Door Lining
26	Inner Glass-Oven Door
27	Plug-Oven Door Lining
28	Screw 10-24×2-3/8“
