1883^0A 08 – OVEN CONTROL PANEL

1883^0A 08 – OVEN CONTROL PANEL

Written by

in

1883^0A 08 – OVEN CONTROL PANEL

Products

PositionProduct
1White – Right
1Almond – Right
1Golden Wheat-Right
1Golden Wheat-Left
1Upper Oven Body Side (Avocado-Left)
1Upper Oven Body Side (Avocado-Right)
1Upper Oven Body Side (Coffee-Left)
1Upper Oven Body Side
1White – Left
1Upper Oven Body Side (Coffee-Right)
1Almond-Left
2WPL 324791
3Screw 6-32×3/8“
4Pop Rivet
5Retainer
6WP112432 Whirlpool Nut Assembly
7Wire Cover
8Shield-Wire
9Bracket-Fluorescent Lamp (Right)
10Holder-Fluorescent Lamp (Left)
10Holder-Fluorescent Lamp (Right)
10Holder-Fluorescent Lamp
11Fluorescent Lamp (20 W – 24“)
12WPL 286889
13Fluorescent Lamp Glass
14Lower Retainer-Lamp Glass
15Screw 6-32 x 3/8“
16Screw 6-32 x 1/2“
17Spring – Lamp Glass End Trim (Lt or Rt)
18End Trim – Lamp Glass (Lt or Rt)
19Screw 6-32 x 1/2“
20Almond
20White
20Golden Wheat
20trim-filter
20WPL 323822
20WPL 323821
21WPL 321660
21Cover-Vent
21WPL 321663
21WPL 321662
21WPL 321664
21WPL 321661
22Almond
22Upper Retainer-Lamp G
22upper retainer-lamp glass
22White
22Upper Retainer-Lamp Glass (Coffee)
22Golden Wheat
23Screw 10-32 x 5/8“
24Hinge Pin
25Washer
26lower hinge-oven door
27Bracket-Oven Orifice
28Support-Upper Oven (Lt. or Rt.)
29baffle-oven burner
30Access Plate
31Oven Side-Left
32Oven Top
33WPL 323890
33Oven Cabinet Top
33Almond
33WPL 323889
33Golden Wheat
33White
34Insulation-Sides, Top & Back (1 Piece)
35oven
36Holder-Oven Lamp Bulb
37Thermostat Bulb Clip (2 Required)
38WPL 305541
39WPL 305628
40Oven Lamp Bulb
41WPL 305629
42WPL 288655
43WPL 325485
44WPL 99139
45WPL 281781
46WPL 98761
47WPL 321162
48WPL 292912
49WPL 292913
50WPL 324745
51WPL 324159
52WPL 102559
53WPL 281846
54WPL 308010
55WPL 281992
56WPL 292907
57WPL 281845
58WPL 293051
59Keps Nut 8-32
60WPL 235134
61WPL 299263
62WPL 293049
63WPL 323873
64WPL 97411
64WPL ARI8787A98
65WPL 97003
66Ballast
67WPL 109180
68WPL 293747
69White-Right
69WPL ARI8788A26
69Coffee-Left
69White-Left
69Coffee-Right
69Avocado-Left
69Golden Wheat-Left
69Almond-Left
69Almond-Right
69Avocado-Right
69Golden Wheat-Right
70Support-Pedestal (Lt. or Rt.)
71Clip
72WPL 313418
73WPL 78565
74WPL 281698
