2075B0A 05 – UPPER OVEN DOOR

Products

Position	Product
1	Screw 10ABx1
2	WPL 21067
3	Seal-Oven Door
4	Lining-Oven Door
4	2075B1A Models
4	2075B0A Models
5	Insulation-Oven Door Plug
6	Insulation-Oven Door Lining
7	WP112432 Whirlpool Nut Assembly
8	Screw 8-32 x 1/2``
9	Keps Nut 8-32
10	Frame-Oven Door
11	Oven Door Handle
12	Screw 6-20x3/8``
13	Oven Door Glass-Outer
14	Door Glass Retainer (6 Req)
15	Retainer-Oven Door Insulation
16	Retainer-Oven Door Glass
17	Hinge-Oven Door (Rt. or Lt.)
18	Inner Glass-Oven Door
19	Washer
20	Screw 10-32x3/8``
