2075B1A 04 – LOWER OVEN DOOR

Products

Position	Product
1	WP112432 Whirlpool Nut Assembly
2	Insulation Retainer-Oven Light
3	Rear Oven Vent Box
4	Main Back
5	Spacer (4 Req)
6	Side Trim (Lt. or Rt.)
7	Left
7	Right
7	Cabinet Side
8	Hinge Box Asm. Lt or Rt
9	Hinge Angle-Lt. or Rt.
11	Cabinet Bottom
12	Insulation Retainer-Ov. Top (Lo)
13	Insulation Retainer-Btm. (Up.)
14	Insulation (Lt. or Rt.)
15	Insulation Retainer-Oven Side (lt. or Rt.)
16	WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V
18	Cabinet Back
20	Top Oven Vent Box
21	Cover Plate-Thermostat Bulb
23	Screw 10-32 x 5/8“
24	Center Front Trim
25	Cover
26	Washer
27	Bottom Channel-Lt. or Rt.
28	Screw 10 – 32 x 1/4“
29	Speed Nut 10-32
30	Upper Oven 2075B1A Model
30	Bake Element
30	Lower Oven 2075BOA Model
30	Bake Element
31	Lower Trim
32	2075B0A Model
32	2075B1A Model
32	Lower Oven Body
33	Lower Oven Door
34	Lower Oven Seal Lt or Rt
35	2075B1A Model
35	2075B0A Model
35	Front Frame
36	2055B0A Model
36	Upper Oven Body
36	2055B1A Model
37	Thermostat Bulb-Retainer (2 Req)
38	2055B0A Model
38	2055B1A Model
38	WPL ARI9172A32
39	WPL 325532
40	Insulation Oven Top & Sides (1 Piece)
41	Insulation Retainer-Oven Top
42	Insulation Retainer-Cabinet Top
43	Retainer-Oven Light Lens
44	Gasket-Lens
45	Holder-Oven Light Bulb
46	Oven Lamp Bulb
47	Lens-Oven Light
48	Screw 10 – 32 x 17/32“
49	Broiler Element Support
50	WPL 326297
51	Oven Rack Guide-Rt. or Lt.
53	WPL 294679
54	Oven Vent Clamp
55	WPL ARI9173A51
55	WPL 331670
55	WPL 325918
56	WPL 291123
58	Oven Rack (2 Req)
59	WPL 331592
59	WPL ARI9174A98
59	2055B0A Model
60	Broiler Element
61	Screw 10ABx3/8“
62	Raceway
63	Cover Plat
64	WPL 114300
