2233W0A 02 – MAIN TOP

Products

Position	Product
1	Push Switch-Oven Light
2	WPL 322305
3	Infinite Control (Right)
3	Infinite Control (Left)
4	Selector Switch
5	WPL 78565
6	Knob-Clock
7	Wire Cover-Backguard
8	Nut-Trim 3/8-27
9	Lock Nut
10	Indicator Light (Oven & Clean)
11	2214, 2224, 2234, 2244 0A & 1A Models
12	Indicator Light-Oven
13	WP112432 Whirlpool Nut Assembly
14	Support-Backguard (Left)
14	Support-Backguard (Right)
15	Screw 10-32×7/16“
16	All 2214 & 2234 Models
17	Golden Wheat 2214H & 2234H
17	Avocado 2214A
17	Coffee 2214C
17	White 2214W &2234W
17	Almond 2214L & 2234L
18	Screw 6-32×3/8“
19	Bezel-Backguard
20	Knob-Selector Switch
21	Knob-Infinite Control (4 Required)
22	Knob-Oven Thermostat
23	Bottom-Wire Cover
24	Lens-Indicator Light (2 Req)
25	Space
27	Knob-Clock (Start & Stop Time)
28	Speed Nut 10 – 32
29	Clip
