2276W1A 04 – MAIN TOP

Products

PositionProduct
1Medallion (2 Req) All 2101 Models
26“ Surface Element (1 Req) All 2101 Models
36“ Burner Bowl (1 Req) All 2101 Models
4Screw 10ABx1/2“
9Bracket-Main Top Hinge (2 Req)
10Hinge-Main Top
10Left
10Right
12Bottom-Burner Box
13Switch, Fluorescent Light
14Screw 10-16×7/16“
15WPL 321162
16Support Rod-Main Top
17Clip
18Main Top
18Main Top (Chrome)
18Golden Wheat
18Almond
18White
198“ Burner Bowl (1 Req) All 2101 Models
208“ Surface Element (1 Req) All 2101 Mod.
21Term. Block w/Leads-All 2101 Models
22Screw 7-32×5/16“(2 Req) All 2101 Models
23Bracket-Term. Block (2 Req) All 2101 Mod.
