2326^0A 05 – OVEN DOOR

Products

Position	Product
1	Screw 10-16×7/16“
2	Screw 10-32×1“
3	Hex Nut 10-32
4	Screw 10-32×7/16“
5	Washer
6	Ground Strap
7	Range Service Mounting Plate
8	Wire Shield-Lower
9	Main Back
10	Screw 6-32×7/8“
11	Strike-Main Top (Lt. or Rt.)
12	Spacer-Main Top (2 Req)
13	Bracket-Body Side (Lt. or Rt.)
14	Almond
14	White
15	Support-Storage Drawer (Lt. or Rt.)
16	Front Slide Block-(Lt. or Rt.)
17	Screw 10-32×17/32“
19	Leg Leveler (4 Req)
20	Rear Slide Block – Lt. or Rt.
21	Screw 8 – 32 x 3/8“
22	Screw 10ABx1/2“
23	spring-oven door (lt. or rt.)
24	Screw
25	Right
25	Left
26	Retainer-Bottom Insulation
27	Vent Tube
28	Thermostat Bulb Clip (2 Required)
29	Insulation-Service Cord
30	Junction Block
31	Shield-Upper Wire
32	Insulation-Oven Top & Sides (1 Piece)
33	Insulation-Oven Back & Bottom (1 Piece)
34	All 2214, 2224 1A & 2A Models
35	Drawer, Utility
36	Dart-Button Head (2 Required)
37	WPL 21067
38	Front Frame
39	Base w/Levelers (Lt. or Rt.)
40	Storage Drawer
41	WPL 326073
41	WPL 326077
42	Handle-Broiler Door
43	WPL 295850
44	WPL 325883
45	Oven Lamp Bulb
46	Holder-Oven Light Bulb
47	WPL 326047
48	main chassis (almond)
49	WPL 331592
51	WPL 326360
52	Support-Broiler Element
54	WPL 326297
55	WPL 326068
62	Ballast
