2382^2A 03 – MAIN TOP

Products

Position	Product
1	Medallion (2 Req) All 2101 Models
2	6“ Surface Unit (Lt. Front & Rt. Rear)
3	6“ Burner Bowl (1 Req) All 2101 Models
4	Screw 10-32×7/16“
5	Keps Nut 8-32
6	Washer
7	Strike-Main Top (2 Required)
8	Catch-Strike
9	Bracket-Main Top Hinge (2 Req)
10	Right
10	Left
12	Burner Box Bottom
13	Switch, Fluorescent Light
14	WPL 316365
15	WPL 321162
16	Support Rod-Main Top
17	Clip
18	White
18	Main Top (Coffee)
18	Main Top (Avocado)
18	Main Top (Golden Wheat)
18	Almond
19	8“ Burner Bowl (1 Req) All 2101 Models
20	8“ Surface Unit (Rt. Front & Lt. Rear)
21	Terminal Block w/Wire Lead (4 Required)
22	Screw 7-32×5/16“(2 Req) All 2101 Models
