| 1 | Screw 6-20x3/8`` |
| 2 | End Cap-Backguard (Lt. or Rt.) |
| 3 | Support-Backguard (Lt. or Rt.) |
| 4 | Crosstie-Backguard |
| 5 | Bracket-Term. Block (2 Req) All 2101 Mod. |
| 6 | Medallion (4 Req) |
| 6 | Medallion (4 Required) |
| 6 | Medallion (4 Required) |
| 7 | 2454X3A Models |
| 7 | 6`` Surface Unit (Lt. Rt. Rr. & Lt. Frt.) |
| 7 | 6`` Surface Element-Lt. Front & Rt. Rear |
| 8 | 6`` Burner Bowl (1 Req) All 2101 Models |
| 9 | Screw 10-16x7/16`` |
| 10 | Screw 10ABx1/2`` |
| 11 | Retainer-Main Top (2 Required) |
| 12 | W10311986 Whirlpool Dishwasher Lower Rack |
| 13 | Cover-Controls |
| 14 | Oven Thermostat |
| 14 | Lower Oven Thermostat |
| 14 | 2454X2A, 3A Models |
| 15 | WPL 78565 |
| 16 | Selector Switch |
| 17 | Infinite Control (Right) |
| 17 | Infinite Control Switch |
| 17 | Infinite Control (Left) |
| 17 | WPL 320944 |
| 18 | 2454X2A, 3A Models |
| 18 | Burner Box Bottom |
| 18 | Burner Box Bottom |
| 19 | Knob-Infinite Control (4 Req) |
| 20 | Knob-Selector Switch |
| 21 | Knob-Thermostat |
| 22 | Pad, Sound |
| 23 | Lens-Indicator Light |
| 24 | Button-I.D. (Infinite)-4 Required |
| 25 | Indicator Light |
| 25 | Indicator Light |
| 25 | Indicator Light-Oven |
| 26 | Insulation-Corrugated |
| 27 | Screw 10-32x3/8`` |
| 28 | Strap-Hold Down (Rt. or Lt.) |
| 29 | Main Top |
| 30 | Term. Block w/Leads-All 2101 Models |
| 31 | Screw 7-32x5/16``(2 Req) All 2101 Models |
| 32 | 2454X3A Models |
| 32 | 8`` Surface Unit (Rt. Front) |
| 32 | 8`` Surface |
| 33 | 8`` Burner Bowl (1 Req) All 2101 Models |
| 34 | Clock w/4 Hr. Timer |
| 35 | Knob-Clock (Start & Stop Time) |
| 36 | Bezel-Clock |
| 37 | Glass-Clock |
