| 2 | Screw 10-32x1`` |
| 3 | Hex Nut 10-32 |
| 4 | Screw 10-32x7/16`` |
| 5 | Washer |
| 6 | Ground Strap |
| 7 | Range Service Mounting Plate |
| 8 | Wire Shield-Lower |
| 9 | Main Back |
| 10 | WP112432 Whirlpool Nut Assembly |
| 12 | Spacer-Main Top (2 Req) |
| 14 | Body Side (Lt. or Rt.) (Black) |
| 15 | Support-Storage Drawer (Lt. or Rt.) |
| 16 | Front Slide Block-(Lt. or Rt.) |
| 17 | Screw 10-32x17/32`` |
| 19 | Leg Leveler (4 Req) |
| 20 | Rear Slide Block - Lt. or Rt. |
| 21 | Screw 8 - 32 x 3/8`` |
| 22 | Screw 10ABx1/2`` |
| 23 | Spring-Oven Door (Lt. or Rt.) |
| 24 | Screw |
| 25 | Hinge-Oven Door |
| 25 | Left |
| 25 | Right |
| 26 | Retainer-Bottom Insulation |
| 27 | Vent Tube |
| 28 | Thermostat Bulb Clip (2 Required) |
| 29 | Insulation-Service Cord |
| 30 | Junction Block |
| 31 | Shield-Upper Wire |
| 32 | Insulation-Oven Top & Sides (1 Piece) |
| 33 | Insulation-Oven Back & Bottom (1 Piece) |
| 34 | All 2234 & 2244 Models |
| 35 | Insulation Retainer-Rt. or Lt. |
| 36 | Dart-Button Head (2 Required) |
| 37 | WPL 21067 |
| 38 | Front Frame |
| 38 | Front Frame |
| 38 | WPL 326042 |
| 39 | Base w/Levelers (Lt. or Rt.) |
| 40 | Storage Drawer |
| 41 | WPL 326078 |
| 42 | Handle-Broiler Door |
| 43 | WPL 295850 |
| 44 | WPL 325883 |
| 47 | WPL 326293 |
| 48 | main chassis (almond) |
| 49 | WPL ARI11211A2 |
| 49 | WPL 293098 |
| 49 | WPL 331592 |
| 51 | WPL 326360 |
| 52 | Support-Broiler Element |
| 53 | Screw 10-16x7/16`` |
| 54 | WPL ARI11212A9 |
| 54 | WPL 293099 |
| 54 | WPL 326297 |
| 55 | WPL 326068 |
| 56 | WPL 327378 |
| 59 | WPL 326495 |
| 60 | WPL 326935 |
| 61 | WPL 319163 |
| 61 | WPL 331867 |
| 61 | WPL ARI11213A8 |
| 62 | Screw 10ABx1/2`` |
