2539 02 – BODY

Products

Position	Product
1	EXTRUSION, OUTSIDE FRAME
2	SPACER, NYLON
3	W11117769 Whirlpool Refrigerator Leveler
5	HINGE, DOOR (LH)(TOP)
6	PASSAGE, AIR (LFT)
7	MAIN OVEN ASSY.
8	HINGE, DOOR (LH)(BOTTOM)
9	GUIDE
10	SCREW, BAFFLE PLATE
11	BRACLET, SUPPORT
13	WP7112P004-60 Whirlpool Thermal Clip
14	CONTACT, OVEN RECEPTACLE
15	RETAINER, ELEM RECEPTACLE
16	OVEN ELEMENT RECEPTACLE
17	WASHER, RETAINING
18	LENS, LIGHT
19	CLIP, LIGHT LENS
20	SEAL STRIP
21	SEAL STRIP
22	SEAL STRIP
23	RETAINER, SEAL TOP
24	TRIM
25	SEAL STRIP
26	SEAL RETAINER, CENTER
27	SEAL STRIP
28	SEAL STRIP
29	SEAL STRIP
30	SEAL RETAINER, RIGHT
31	EXHAUST GUIDE BAR ASSY.
32	EXHAUST ASSY.
32	EXHAUST ASSY.
33	COVER, EXHAUST FRONT
34	STOP, SLIDE
35	NOT REQUIRED PART OR SEE NOTE
36	BOX, EXHAUST
37	BOTTOM, OVEN ASSY
38	ROTISSERIE MOTOR & DRIVE ASSEM
39	LIGHT RECEPTACLE
40	RANGE ONLY 40W 120V APPL BULB
41	SHIELD, WIRE
42	PANEL, INSPECTION
43	MOUNT, SWITCH ASSY.
44	RELAY
45	TRANSFORMER
46	GROMMET
47	WIRING BOX ASSY.
48	NUT
49	WIRE CONNECTING LUG
50	BOTTOM, OVEN
51	PASSAGE, AIR (RT)
52	HINGE, DOOR (RH)(BOTTOM)
53	HINGE, DOOR (RH)(TOP)
54	CONTROL, BROWNING (GREEN DOT)
55	CONTROL, TOP HEAT (RED DOT)
56	BRACKET, MOUNTING
