2570B00 02 – MAIN TOP

Products

Position	Product
1	Wire Cover
2	Baffle-Wires
3	WP112432 Whirlpool Nut Assembly
4	Wire Cover-Controls (Right)
5	Insulation-Controls (Right)
6	Wire Connector (2 Required)
7	2570B00
7	Infinite Control-Rt. Frt. & Lt. Rr.
8	2570B00
8	Infinite Control-Rt. Rr. & Lt. Frt.
8	WPL 320944
9	2570B00
9	Oven Thermostat
9	2570B10
10	Push Switch (Lock-Unlock)
11	Insulation-Controls (Left)
12	Push Switch-Oven Light
13	Lock Nut
14	Selector Switch
14	Selector Switch
14	2570B00
15	Speed Nut 10 – 32
16	Control Panel
18	Indicator Light (Oven & Clean)
19	Wire Lead w/Resistor
20	WPL 78565
21	Lens-Indicator Light (2 Req)
22	Knob-Oven Thermostat
22	2570B10
22	2570B00
23	2570B10
23	Knob-Selector Switch
23	Knob-Selector Switch
24	Mounting Bracket – End Cap (Right)
24	Bracket-End Cap & Control Panel
24	Mounting Bracket – End Cap (Left)
25	End Cap – Control Panel (Right)
25	End Cap
25	End Cap – Control Panel (Left)
26	Screw 10ABx1/2“
27	Knurled Nut
28	Knob-Infinite Control
28	2570B10
28	2570B00
29	Clock w/1 Hr. Timer
30	Knob-Clock (Start & Stop Time)
31	Cover-Clock
