2570B10 06 – GRIDDLE

Products

Position	Product
	xWire Harness
160	Screw 10ABx1
161	Screw 10-32 x 1/2“
162	WPL 21067
163	Seal-Inner Glass
164	Screw 10-32×3/8“
165	Gasket-Oven Door
166	Washer
167	Screw 10-32×5/16“
168	Hinge-Lt. or Rt.
169	WP660532 Whirlpool Oven Surface Element
170	Door Glass Retainer (4 Req)
171	Screw 10-32×17/32“
172	Spacer-Oven Door Glass (Lt. or Rt.)
173	WP487353 Whirlpool Refrigerator Screw
174	Screw 10 – 32×3/8“
175	Door Glass Retainer (6 Req)
176	Screw 8-32 x 1/2“
177	Outer Glass-Oven Door
177	2570B00
177	2570B10
178	Frame-Door
179	Keps Nut 8-32
180	Handle-Oven Door
181	Screw 10-32 x 5/8“
182	Screw 10 – 32 x 1/4“
183	Baffle-Oven Door Lining
183	2570B10
183	2570B00
184	Insulation-Top Corner (Rt. or Lt.) 2570B00
185	Oven Door Glass-Intermediate
186	2570B10
186	Retainer-Oven Door Insulation
186	2570B00
187	Center Glass-Oven Door
187	Oven Door Glass-Inner
187	Inner Glass-Oven Door
188	Retainer-Oven Door Glass
189	Insulation-Oven Door (Top)
190	Lining-Oven Door
191	Inner Glass-Oven Door
192	Selector Switch
192	Plug-Oven Door Lining
192	Infinites-2570B00
192	Infinites-2570B10
192	Controls
