2763W0A 04 – OVEN DOOR

Products

Position	Product
1	Wire Shield
2	Spacer-Main Top
3	Retainer-Insulation (Lt. or Rt.)
4	Insulation-Oven Back & Bottom
5	WPL 316365
6	Retainer-Bottom Insulation
7	Screw 10-32 x 5/8“
8	Grommet – Screw (8 Req.)
9	Body Side (Lt. or Rt.)
9	Body Side-Lt. or Rt.) (White)
9	Body Side-Lt. or Rt.) (Almond)
9	Body Side-Lt. or Rt.) (Golden Wheat)
10	Bracket-Support & Base (Lt. or Rt.)
11	Spring-Oven Door (Lt. or Rt.)
12	Support-Storage Drawer (Lt. or Rt.)
13	Screw 10-32×17/32“
14	Storage Drawer
15	Left
15	Right
15	Hinge-Oven Door
16	Screw 8 – 32 x 3/8“
17	Rear Slide Block – Lt. or Rt.
18	Front Frame
19	Vent Tube
20	Cover Plate-Thermostat Bulb
21	Main Back
22	Washer
23	Screw 10-32×7/16“
24	Hex Nut 10-32
25	Ground Strap
26	Screw 10-32×1“
27	Junction Block
28	Range Service Mounting Plate
29	Insulation-Oven Top & Sides (1 Piece)
30	Insulation (Rt. or Lt.)
31	WPL 293099
32	WPL 293098
33	WPL 305408
34	Cover
35	Thermostat Bulb-Retainer (2 Req)
37	Oven Body
38	Washer
39	WP303896 Whirlpool High Limit Thermostat
41	Front Slide Block-(Lt. or Rt.)
42	White
42	Front Panel-Storage Drawer
42	Golden Wheat
42	Front Panel-Storage Drawer (Black)
42	Almond
43	WPL 323929
44	Leg Leveler (4 Required)
45	WPL 286357
47	WPL 295850
48	Bake Element
49	Cover Plate
52	WPL 305409
53	Broil
54	Support-Broiler Element
55	WP112432 Whirlpool Nut Assembly
56	Sh
57	WPL 323931
