2763W0A 07 – CONTROL PANEL

Products

Position	Product
1	WP112432 Whirlpool Nut Assembly
2	Baffle - Airway
3	Foam Strip
4	Fuse-15 Amp.
5	Fuse Holder
6	Side-Compartment
7	Air Duct
8	Front - Blower Mounting Plate
9	Fan Blade
10	Support - Blower Motor
11	Motor - Blower
12	Nut 6-32
13	Set Screw 10-32
14	Mounting Plate - Blower
15	WPL 109180
