2843W0A 05 – CONTROL PANEL

2843W0A 05 – CONTROL PANEL

Written by

in

2843W0A 05 – CONTROL PANEL

Products

PositionProduct
1Almond – Right
1Almond-Left
1Upper Body Side
1White – Left
1White – Right
3Pedestal-Upper Oven
3WPL 325283
3WPL 325287
3WPL 325289
3WPL 325293
4WP112432 Whirlpool Nut Assembly
5Cover Plate
6Wire Cover
8Wire Cover-Fluorescent
9Screw 6-32 x 3/8“
10Fluorescent Lamp Glass
11Fluorescent Lamp (20 W – 24“)
12Holder-Fluorescent Lamp (Right)
12Holder-Fluorescent Lamp (Left)
12Holder-Fluorescent Lamp
13Bracket-Fluorescent Lamp (Right)
14Shield-Wire
15WPL 324058
16Retainer
17Pop Rivet
18WPL 324791
19Oven Side-Left
20Thermostat Bulb Clip (2 Required)
21Oven Back
22WPL 305628
23WPL 305629
24Push Switch-Oven Light
25Oven Bottom
26Insulation
27Oven Cabinet Bottom
28WPL 322937
29WPL 320257
29WPL 322949
29Vent Side
30WPL 322935
30Vent End
30WPL 322933
31WPL 320261
32Almond
32upper retainer-lamp glass
32White
33Cover-Vent
33WPL 321660
33WPL 321664
34Screw 6-32×3/8“
35Lower Retainer-Lamp Glass
36Spring – Lamp Glass End Trim (Lt or Rt)
37End Trim – Lamp Glass (Lt or Rt)
38Screw 6-32 x 1/2“
39trim-filter
39White
39Almond
40Knurled Nut
41WPL 324159
42Lock Nut
43WPL 281781
44Push Switch (Fluorescent Light)
45Broiler Element Support
46Screw 10 – 32 x 17/32“
47WPL 294297
48Almond
48White
48WPL ARI11492A4
49Insulation-Sides, Top & Back (1 Piece)
50WPL 319844
51WPL 305127
52Screw 10-32 x 1/2“
53WPL 319842
54WPL 97003
55WPL 292912
56WPL 292913
57WPL 305134
58WPL 299988
59WPL 299987
60WPL 295850
61WPL 308009
62WPL 281846
63WPL 102559
64WPL 292907
65lower hinge-oven door
66WPL 316365
67Hinge Pin
68Washer
69WPL 280491
70WPL 286326
71WPL 305130
72WPL 293051
73Keps Nut 8-32
74WPL 235134
75Screw 10-32×3/8“
76WPL 299263
77WPL 323873
78WPL ARI11493A7
78WPL 97411
78WPL 78565
81Ballast
82WPL 109180
83WPL 293747
84WPL 323949
85Holder-Oven Light Bulb
86Oven Lamp Bulb
87WPL 323970
88WPL 324339
89WPL 324338
90WPL 319430
