2872W0A 02 – MAIN TOP

Products

Position	Product
1	Medallion (2 Req) All 2101 Models
2	6“ Surface Unit (Lt. Front & Rt. Rear)
3	6“ Burner Bowl (1 Req) All 2101 Models
4	Screw 10-32×7/16“
5	Keps Nut 8-32
6	Washer
7	Strike-Main Top (2 Required)
8	Catch-Strike
9	Bracket-Main Top Hinge (2 Req)
10	Right
10	Left
11	WPL 321162
12	Support Rod-Main Top
13	Burner Box Bottom
14	Clip
15	WPL 316365
16	Main Top (Coffee)
16	White
16	Main Top (Avocado)
16	Almond
16	Main Top (Golden Wheat)
17	8“ Burner Bowl (1 Req) All 2101 Models
18	8“ Surface Unit (Rt. Front & Lt. Rear)
19	Term. Block w/Leads-All 2101 Models
20	Screw 7-32×5/16“(2 Req) All 2101 Models
21	Bracket-Term. Block (2 Req) All 2101 Mod.
