2893^0A 08 – SWITCHES AND MICROWAVEadmin2025-04-26T10:53:53+00:002893^0A 08 – SWITCHES AND MICROWAVE
Products
| Position | Product |
|---|
| xCircuit Diagram |
| 1 | Screw, Truss Hd. Tapping, 4 x 8 mm, Z1-2 |
| 2 | Back-up Battery |
| 3 | Screw, Truss Hd. Tapping, 4 x 10 mm, Z1-2 |
| 4 | Magnetron Gasket xxx |
| 5 | Caution Label and Name Plate |
| 6 | Oven Cavity xxx (Also order 780524 Caution Label Key No. 5 and One 780526 Circuit Diagram when repla |
| 7 | Wiper, Ram |
| 8 | Special Nut, Temperature Probe Jack |
| 9 | Jack, Temperature Probe |
| 10 | 5-Wire Harness with Socket |
| 11 | Temperature Probe |
| 12 | Cavity Frame |
| 13 | Plastic Stopper, Glass Tray |
| 14 | Plastic Stopper |
| 15 | Ferrite Rubber xxx |
| 16 | Trim Bracket xxx |
| 17 | Glass Tray |
| 18 | Rack Holder |
| 19 | Metal Rack |
| 20 | Stirrer Cover |
| 21 | Hinge, Lower xxx |
| 22 | Bolt, Hex Hd. with Phillips Slot, 5 x 12 mm Z1 |
| 23 | Retainer, Nut (2) |
| 24 | Special Washer |
| 25 | Collar, Stirrer Shaft |
| 26 | Stirrer Fan Ass`y |
| 27 | Stirrer Shaft |
| 28 | Washer, 5 mm U |
| 29 | W10439651 Whirlpool Air Conditioner Motor Drive |
| 30 | Air Guide, Stirrer, Left |
| 31 | Screw, Pan Hd. Tapping, 3 x 8 mm, Z1-2 |
| 32 | Nut, Hex Hd. with Washer, 5 mm, Z1 |
| 33 | Lamp Socket (UL Listed) |
| 34 | Lamp, 120V 30W |
| 35 | Bracket, Lamp Socket |
| 36 | Escutcheon, Control |
| 37 | Wire Clip |
