2893W0A 02 – POWER LOCK

2893W0A 02 – POWER LOCK

Written by

in

2893W0A 02 – POWER LOCK

Products

PositionProduct
1Medallion (2 Req) All 2101 Models
26“ Surface Unit (Lt. Front & Rt. Rear)
36“ Burner Bowl (1 Req) All 2101 Models
4Screw 10-32×7/16“
5Keps Nut 8-32
6Washer
7Strike-Main Top (2 Required)
8Catch-Strike
9Bracket-Main Top Hinge (2 Req)
10Right
10Left
10Hinge-Main Top
12Burner Box Bottom
13Switch, Fluorescent Light
14WPL 316365
15WPL 321162
16Support Rod-Main Top
17Clip
18Main Top
18Main Top (Avocado)
18Main Top (Coffee)
18Almond
18White
18Main Top (Golden Wheat)
198“ Burner Bowl (1 Req) All 2101 Models
208“ Surface Unit (Rt. Front & Lt. Rear)
21Term. Block w/Leads-All 2101 Models
22Screw 7-32×5/16“(2 Req) All 2101 Models
23Bracket-Term. Block (2 Req) All 2101 Mod.
