2893W0A 07 – CABINET

Products

Position	Product
	xWire Harness
1	WPL 78565
2	Screw 8-32×3/8“
3	Auxiliary Thermostat
4	Selector Switch
5	Infinite Control (Rt. & Lt. Rear)
6	Infinite Control (Rt. & Lt. Rear)
7	Mounting Bracket-Controls
8	Indicator Light
9	Push Switch (Lock-Unlock)
10	Push Switch – Oven Light
11	Lock Nut
12	Knurled Nut
13	Lens-Indicator Light
14	Knob-Infinite Control (4 Req)
15	Push Switch (Fluorescent Light)
16	Knob-Selector & Thermostat Switch
17	Screw 10-32×5/16“
18	Thermostat
19	Speed Nut 8-32
20	Wire Lead w/Resistor (10K,4-5 Watt)
21	Fixed Input Control
22	Clock w/1 Hr. Timer
23	Selector Switch
23	Knob-Clock (Start & Stop Time)
23	xWire Harness (Controls)
23	Main Top
