2893W0A 10 – DOOR

Products

Position	Product
1	Bottom Plate
2	Step-down Transformer, Control Circuit, P6T-3826
3	Screw, Bind Hd. Tapping, 4 x 12 mm, Z1-2
4	Hinge Voltage Capacitor with Resistor and Rectifier, 0.85 mfd 2.4 KV
5	Nut, Hex Hd. with Washer, 4 mm, Z1-1
6	Fuse, 15A
7	Fuse Holder (UL Listed)
8	Varistor
9	Terminal Board
10	High Voltage Transformer, 120V Input, H6T-3826
11	Bolt, Hex Hd. Machine with Spring Washer and Bolt Washer, 6 x 16 mm, Z1
12	Screw, Pan Hd. Diacut, 4 x 10 mm, Z1
13	Wire Clip
