30-0127-23-03 07 – BODY PARTS

Products

Position	Product
1	GROMMET-MAINTOP
2	GROMMET
3	PANEL BODYSIDE-ALMD
4	WCI 3051009
5	SUPPORT-CONTROL PNL
6B	OVEN LINER-TOP
6A	OVEN LINER-SIDE LH
6	OVEN LINER-SIDE RH
6C	WCI 3206196
7	WCI 3017713
8	SEAL OVEN DOOR
9A	HINGE ASSY-RH
9	318348801 Frigidaire Oven Left Side Door Hinge
10	5304500008 Frigidaire Oven Screw
11	SPRING-OVEN DOOR
12	WCI 3016158
13	OVEN-BOTTOM
14	WCI 3051511
16	316116400 Frigidaire Oven Light Socket
17	316538904 Frigidaire Oven Lamp Light
18	SUPPORT-OVEN BOTTOM
19	WCI 3131039
20	WCI 3131040
21	LEG LEVELLER (4)
22	RAIL-BASE
23	BRACKET-INSTALLATION (2)
24	MAIN BOTTOM
25	INSULATION WRAPPER
26	WCI 3131044
27	WCI 3131045
28	SUPPORT-REAR OVN (2)
29	CHANNEL – MAIN WIRE
30	WCI 3131047
31	SCREW, 8 X 5/8, SPARK MODULE
32	5303912606 Frigidaire Oven Range Spark Module 2+0 4 Large Terminals
33	WCI 3017173
34	SNAP – BUSHING
35	BURNER BOX
36	SHIELD-BURNER BOX RH
36A	SHIELD-BURNER BOX LH
37	WCI 3131031
