30-1049-23-01 06 – BURNER, MANIFOLD AND GAS CONTROL

30-1049-23-01 06 – BURNER, MANIFOLD AND GAS CONTROL

Written by

in

30-1049-23-01 06 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
1WCI 5303016997
2WCI 3202794
3WCI 3202795
4WCI 3202796
4ABOLT VALVE MTG
5WCI 5303201274
6WCI 5303201273
7CAP-TOP PILOT
8WCI 3201276
9Tubing`thermo/pilot `3/16 ,alum
10WCI 3203395
11WCI 3018603
12WCI 3203391
13WCI 3203265
145303013272 Frigidaire Oven Nut
15WCI 3202800
16WCI 3204583
175304506427 Frigidaire Oven Range Surface Burner (White)
18WCI 3203393
19SHIELD-PILOT, STAINLESS STEEL, (2)
20WCI 5303201277
