30-3858-66-05 05 – BURNER, MANIFOLD AND GAS CONTROL

Products

Position	Product
*26085	WCI 3051420
1	WCI 3131283
2	BAFFLE-OVN BURNER
3	WCI 079T028P01
4	WCI 3131290
5	WCI 079T032S02
6	WCI 3018617
7	BURNER TUBE-RF & LF
8	WCI 079T033H02
9	WCI 079T033H03
11	WCI 247T074P01
12	IGNITER-TOP BURNER (4)
13	MANIFOLD, PIPE
14	WCI 3017846
15	ELBOW 1/2 NP TO 9/16-24
16	316035200 Frigidaire Ignition Switch
17	5303935068 Frigidaire Flat Igniter
18	5303935066 Frigidaire Oven Flat Igniter 17" Leads
19	5304505695 Frigidaire Oven Module
20	WCI 455T008P02
21	NUT
22	NUT COMPRESSN (4)
23	FITTING-LOXIT (8)
24	TUBE-REGUL TEE
25	TUBE ALUM 3/8
26	TUBE-VALVE TO MIXER ELBOW
27A	5300809968 Frigidaire Dishwasher P-1 Washer
27	5303208499 Frigidaire Safety Gas Valve
28	5303935125 Frigidaire Pressure Regulator
29	316091600 Frigidaire Oven Bracket
30	5303013272 Frigidaire Oven Nut
31	SPUD NO 50
32	NUT SPECIAL
33	WCI 136T355W03
