30DGMBWDN0 04 – BURNER, MANIFOLD AND GAS CONTROL

30DGMBWDN0 04 – BURNER, MANIFOLD AND GAS CONTROL

Written by

in

30DGMBWDN0 04 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
15308007974 Frigidaire Pressure Regulator
2WCI 3017164
3PILOT-TOP BURNER (RIGHT)
4NUT – WING
5WCI 08013927
6BAFFLE-OVEN BURNER
7WCI 08013855
8TUBE-OVEN FEED
9WCI 08008363
10TUBE OVEN PILOT
11WCI 3131074
12NUT & SLEEVE
13SUPPORT-OVEN SAFETY VALVE
14WCI 3205598
15WCI 08013942
16WCI 3131067
17STRAP – PILOT SHIELD
18WCI 3131057
19SUPPORT – TOP BURNER
20BURNER – TOP REAR
21BURNER – TOP FRONT
22CLIP-CAPILLARY (NON-ILLUSTRATED)
