31-2377-23-01 03 – BODY PARTS

Products

PositionProduct
1PANEL-SIDE RH ALMD
1APANEL-SIDE LH ALMD
2GUSSET – BKGRD (2)
3BUMPER-COOKTOP (4)
4SCREW-LEVELING (4)
5GLIDE-DRAWER-RH
5RAIL, DRAWER LH
6GUIDE-DRAWER FRNT (2)
7WCI 3051531
8BODY
9WCI 3051511
10316116400 Frigidaire Oven Light Socket
11316538904 Frigidaire Oven Lamp Light
12WCI 3051515
135304524341 Frigidaire Lens
14SPACER, DRAWER RAIL (2)
15WCI 3051562
165304442087 Frigidaire Range Wall Oven Broil Pan and Insert
17RACK-OVEN
185304409888 Frigidaire Oven Terminal Block with Hardware
19WCI 3051755
20CHANNEL-OVEN SUPT
21WCI 3051743
22INSULATION – OVEN WRAP
23BRACKET-THERMO BULB (2)
24WCI 3051744
25INSULATION – OVEN BACK
26WCI 3051637
26GUSSET – REAR (2)
27WCI 3051757
28WCI 3051633
29WCI 3051641
30WCI 3051655
31BRACKET, VENT TUBE
32GASKET, OVEN VENT TUBE
33TUBE-OVEN VENT
