31-3982-00-01 03 – BODY PARTS

Products

PositionProduct
1BACK-MAIN, AUTOLATCH
3CSHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED)
3PNL-B/S-RH-WHITE
3APNL-B/S-LH-WHITE
3DFASTENER-EDGE MTG (NOT ILLUSTRATED)
4WCI 5303271756
5SCREW-LEVELING
5AANTI-TIP KIT (NOT ILLUSTRATED)
5BNUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED)
6316067902 Frigidaire Oven Rack
7WCI 316007002
8PANEL-OVEN BOTTOM
9PAN-BROILER
10WCI 5303131356
12SWITCH-OVEN LIGHT, DOOR FRAME
13WCI 316026800
14316116400 Frigidaire Oven Light Socket
15316538904 Frigidaire Oven Lamp Light
165304524341 Frigidaire Lens
17RETAINER-GLASS
18WCI 316036300
21SPACER-BODYSIDE, (8)
25WCI 3200848
275303284616 Frigidaire Range Bulb Clip Thermostat
293051162 Frigidaire Oven Range Front Broiler Drawer Glide
30ABRACKET-HINGE, MAIN TOP, LH
30BRACKET-HINGE, MAIN TOP RH
41WCI 3131570
443131903 Frigidaire Door/Drawer Bumper
55COVER-FLUE
57COVER-ACCESS
58AWCI 316047700
58316403803 Frigidaire Insulation
58BINSULATION OVEN BACK (NON-ILLUSTRATED)
58CINSULATION, OVEN TOP
59WCI 3051344
625304409888 Frigidaire Oven Terminal Block with Hardware
62A316205500 Frigidaire Oven Nut
63PLATE-GROUND STRAP
64WCI 08067810
65WCI 08010606
665303051140 Frigidaire Broil Element
