31-4967-23-01 03 – BODY PARTS

Products

PositionProduct
1SPACER, BODYSIDE (8)
3PANEL B/S-LH BLACK
3PNL. B/S (LH ALMOND)
3PANEL B/S-RH BLACK
3PNL. B/S (RH ALMOND)
4WCI 3051109
5WCI 3131101
6WCI 3131567
7WCI 3051400
8COVER, LOWER ACCESS
9COVER-FLUE
10316067902 Frigidaire Oven Rack
11WCI 636M004P01
12WCI 3131570
13WCI 3051398
14WCI 316007002
15WCI 3051104
16FUSE-THERMAL CUTOUT
17PAN, BROILER
18WCI 3131356
195304409888 Frigidaire Oven Terminal Block with Hardware
20WCI 711T048P01
21CLIP-TUBING (2)
223051162 Frigidaire Oven Range Front Broiler Drawer Glide
23WCI 3051367
24WCI 3051298
25INSULATION, BOTTOM
26WCI 3051344
27ENUT-HEX BRASS (6) (NON-ILLUSTRATED)
27BINSUL OVEN BACK (NON-ILLUSTRATED)
27WCI 3131104
27AINSULATION, OVEN TOP
27C3131903 Frigidaire Door/Drawer Bumper
27DSCREW-HNG MTG (6) (NON-ILLUSTRATED)
28WCI 3015361
29WCI 3051473
30ASCREW-SET KNOB MTG (NON-ILLUSTRATED)
30WCI 358T158S02
31SHIELD-LATCH
32SHIELD-LATCH (NON-ILLUSTRATED)
33FASTENER, PUSH ON (3)
34SWITCH-LATCH
35WCI 3131363
36316116400 Frigidaire Oven Light Socket
37316538904 Frigidaire Oven Lamp Light
38WCI 3051737
39RETAIN, CATALYST
40SWITCH-OVEN LITE DOOR
41BRKT LIGHT SWITCH
42ROD-LIGHT SWITCH
43WCI 3051251
44BUTTON-REMOVE LIGHT SWITCH
45AWCI 3131305
45SHIELD, HEAT LOWER
46TRIM-VERT B/S (2)
