31-4998-00-02 04 – DOOR PARTS

Products

Position	Product
*11928	5303208655 Frigidaire Reflector Assembly
*11928	ALUM FOIL-B/G GLASS
1	BRKT GLASS (2)
2	WCI 3051148
3	WCI 276T105P02
4	GLASS FRNT
5	WCI 3131256
6	LINER
7	5303131601 Frigidaire Oven Seal
8	WCI 3202151
9	SHIELD-BACKGUARD,REAR WALL
10	WCI 3051728
11	CLIP-RETAINING
12	FSTNR. SPACER (6)
13	SCREW-HANDLE
14	SCREW-DOOR MTG (3)
15A	FSTNR 8AU TYPE (3)
15B	5303300265 Frigidaire Oven Screw
15C	SCREW-DOOR MTG (4) (NON-ILLUSTRATED)
16	WCI 3131322
17	PNL MAIN TOP-WHITE
