31-7968-00-04 07 – BODY PARTS

Products

Position	Product
*12088	SHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED)
*12088	FASTENER-EDGE MTG (NOT ILLUSTRATED)
*12088	WCI 3131305
*12088	316403803 Frigidaire Insulation
1	WCI 665T188P02
3	B/S-LH-(WHITE)
3A	B/S-RH-(WHITE)
4	WCI 3051109
5	WCI 3131101
6	WCI 3131567
7	WCI 3051400
8	CVR-LWR ACCESS
9	COVER-FLUE
10	316067902 Frigidaire Oven Rack
11	WCI 636M004P01
12	WCI 3131570
13	SHIELD, OVEN BOTTOM
14	WCI 316007002
15	WCI 3051104
17	WCI 539T010F01-85
18	WCI 3131356
19	5304409888 Frigidaire Oven Terminal Block with Hardware
20	WCI 711T048P01
21	5303284616 Frigidaire Range Bulb Clip Thermostat
22	3051162 Frigidaire Oven Range Front Broiler Drawer Glide
23	WCI 3051367
24	WCI 3051298
25	INSULATION, BOTTOM
26	WCI 3051344
27	WCI 3131104
27E	NUT-HEX BRASS (6) (NON-ILLUSTRATED)
27A	WCI 3131103
27C	INSULATION, OVEN WRAPPER
27D	SCREW-HNG MTG (6) (NON-ILLUSTRATED)
27B	3131903 Frigidaire Door/Drawer Bumper
28	WCI 3051258
29	WCI 3051473
30A	SCREW-SET KNOB MTG (NON-ILLUSTRATED)
30	WCI 358T158S02
31	SHIELD-LATCH
32	SHIELD-LATCH (NON-ILLUSTRATED)
33	WCI 241T001P01
34	WCI 3131672
35	WCI 3131363
36	316116400 Frigidaire Oven Light Socket
37	316538904 Frigidaire Oven Lamp Light
38	WCI 244T041P01
39	RETAIN, CATALYST
40	SWITCH-OVEN LITE DOOR
41	BRKT LIGHT SWITCH
42	WCI 3131600
43	WCI 174T329P01
44	BUTTON-REMOTE SW
45	WCI 3200848
