Products

Position	Product
A010	Panel Assembly,Rear
A180	VALVE ASSY-INLET
A183	ACJ73350401 LG Washer Water Valve Connector Assembly
A186	MEJ62565301 LG Inlet Hose
A190	AEN72910501 LG Washer Detergent Housing Assembly
A200	SWITCH ASSY-SENSOR
A201	5210FA3427J LG Washer Tube Switch
A202	3W50012U LG Snap Ring
A203	MEG64119601 LG Holder
A230	EAD49973506 LG Power Cord Assembly
A240	EAD62290508 LG Multi Harness
A241	EAM60930604 LG Filter Assembly
A380	Dispenser Assembly
A410	MBL65540803 LG Cap Cover
A390	4861FR3068C LG Clamp
A165	AGM73832002 LG Parts Assembly
A163	HINGE ASSY
A157	AGB73672402 LG Nozzle Assembly
A020	Lid Assembly
A030	Cap,Screw
A040	1SZZEN4017K LG Customized Screw
A050	AGL73961620 LG Front Panel Assembly
A061	EBR80321803 LG Main PCB Assembly
A062	PCB Assembly,Display
A100	MCK67394604 LG Top Cover
A101	MCK67634401 LG Washer Lower Cover
A140	SWITCH ASSY-LOCKER
A150	Box Assembly,Detergent
A151	MAY62020101 LG Washer Detergent Dispenser Box
A152	MBL65460502 LG Softener Cap
A153	MBL65440002 LG Softener Cap
A154	MAY65797101 LG Detergent Box
A184	MEJ62524903 LG Inlet Hose
