| F000 | Cabinet Assembly |
| F100 | HOSE ASSY-DRAIN |
| F090 | MBU62225402 LG Hose Clamp |
| F086 | EAD62285501 LG Single Harness |
| F082 | Cover,Protect |
| F080 | 5859EA1004F LG Water Drain Pump Assembly |
| F070 | Cover,Rear |
| F032 | 4930EA3002A LG Holder |
| F031 | MEG64858801 LG Holder |
| F027 | AFC73529602 LG Assembly Leg |
| F023 | 5040FA4226B LG Damper |
| F020 | AAN73431003 LG Base Cabinet Assembly |
| F016 | ABA74451701 LG Bracket Assembly |
| F150 | EBD50360202 LG Sensor Assembly |
