31HA-5KLX 02 – CONTROL PANEL

Products

Position	Product
1	MAY 3801F002-34
2	MAY 7109P010-60
2	MAY 3801F109-34
3	MAY 3801F006-51
4	MAY 8007P004-60
5	MAY 7602P088-60
5	MAY 7602P097-60
5	MAY 3801F108-45
6	MAY 4005F155-80
7	MAY 7724P010-60
7	MAY 7724P017-60
8	MAY 4005F100-80
8	MAY 7101P061-60
9	MAY 7728P053-60
10	MAY 7706P166-60
11	MAY 7706P097-60
12	MAY 7910P084-60
13	MAY 7711P171-60
14	MAY 7711P172-60
15	MAY 7407P004-60
16	WP4159193 Whirlpool Screw
17	MAY 2620W053-23
18	MAY 3605F144-80
19	MAY 3605F006-80
19	MAY 3605F008-80
20	MAY 7408P005-60
21	WP59002061 Whirlpool Microwave Screw
22	MAY 7101P058-60
23	MAY 7101P074-60
24	SCREW
25	MAY 3604F079-80
26	MAY 7214P001-60
26	MAY 7214P007-60
27	MAY 3807F349-51
27	MAY 3807F348-51
28	MAY 3807F215-80
29	MAY 7711P008-60
29	MAY 7403P179-60
29	MAY 7403P007-60
29	NOT REQUIRED PART OR SEE NOTE FUSE (NOT REQUIRED)
30	MAY 7105P002-60
31	MAY 7401P015-60
31	MAY 7401P020-60
31	MAY 7403P104-60
32	MAY 7726P029-60
32	MAY 7726P030-60
33	MAY 7720P061-60
