37-1042-23-04 06 – BURNERS, DRIP PANS, ELEMENTS

37-1042-23-04 06 – BURNERS, DRIP PANS, ELEMENTS

Written by

in

37-1042-23-04 06 – BURNERS, DRIP PANS, ELEMENTS

Products

PositionProduct
1ASCREW (4) (NON-ILLUSTRATED)
15303935058 Frigidaire Oven Burner Receptacle Kit
2MEDALLION
3318372210 Frigidaire Oven Range 6" 1250W Surface Element
4316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
5316442300 Frigidaire Oven 2100W Coil Element 8
6316048413 Frigidaire Oven Range Chrome 8" Drip Bow
7SUPT BROIL. ELEMNT
8220T017P02 Frigidaire Broil Element
9ASCREW 8 X 18 X 1/2“ HEX WSH HD (2)
9WCI 221T017P01
9BWIRE HARN. SW.
9CKIT BAKE & BROIL EL. WIRE REPAIR
